Split Phase Residential Energy Storage Inverters

S6-EH2P(9.6-16)K03-SV-YD-L-US

9.6K03 / 10K03 / 11.4K03 / 12K03 / 14K03 / 16K03

Product Introduction

The Solis S6 48V Hybrid String Inverter is designed to deliver true energy independence for North American homeowners. Offering flexible power classes from 9.6 to 16kW, this versatile solution supports whole-home backup, lightning-fast switchover during outages, and intelligent ports for seamless integration with existing PV, sheddable load, or generator. Rated for 200A pass-through and compatible with a wide range of battery types and brands. The S6 48V Hybrid makes resilient, cost-effective solar + storage installations easier than ever.

Technical Specifications

    S6-EH2P(9.6-16)K03-SV-YD-L-US

    Input DC (PV side)

    Max. input voltage: 550V
    MPPT voltage range: 100-450V
    MPPT number: 3

    Output AC (Back-up and Off-gird)

    Rated output power: 9.6kW / 10kW / 11.4kW / 12kW / 14kW / 16kW
    Rated output voltage (L1-L2): 220V / 240V

    Efficiency

    Max. efficiency: 96.02%

    General Data

    Ingress protection: TYPE 4X (IP66)

Datasheet Download

Leading Features

48V Hybrid can function on-grid, off-grid or act as aMicrogrid.

Smart port for supporting flexible configurations like AC coupling or generators.

High input current (20A) supports larger modules, improving power density and eliminating clipping.

Integrated 200A pass-through and bypass function fully integrated to limit external hardware, save costs and streamline storage.

The battery's DC side can handle a maximum charge/discharge current of up to 290A, allowing it to store more surplus energy generated by PV systems for better efficiency.

Redefining C&I Storage

Downloads

Datasheet Installation Video Manual
S6-EH2P(9.6-16)K-Global-Datasheet-V3.8
S6-EH2P(9.6-16)K03-SV-YD-L-US
Manual_S6-EH2P(9,6-16)K-SV-YD-H-US_V2.0
